Total Cores

# of Performance-cores

# of Efficient-cores

Total Threads

Max Turbo Frequency

5.8 GHz

Intel® Thermal Velocity Boost Frequency

5.80 GHz

Intel® Turbo Boost Max Technology 3.0 Frequency ‡

5.70 GHz

Performance-core Max Turbo Frequency

5.40 GHz

Efficient-core Max Turbo Frequency

4.30 GHz

Performance-core Base Frequency

3.00 GHz

Efficient-core Base Frequency

2.20 GHz

Cache

36 MB Intel® Smart Cache

Total L2 Cache

32 MB

Processor Base Power

125 W

Maximum Turbo Power

253 W

Supplemental Information

Marketing Status

Launched

Launch Date

Q4'22

Embedded Options Available

Use Conditions

PC/Client/Tablet

Datasheet

View now

Memory Specifications

Max Memory Size (dependent on memory type)

192 GB

Memory Types

Up to DDR5 5600 MT/s
Up to DDR4 3200 MT/s

Max # of Memory Channels

Max Memory Bandwidth

89.6 GB/s

Expansion Options

Direct Media Interface (DMI) Revision

4.0

Max # of DMI Lanes

Scalability

1S Only

PCI Express Revision

5.0 and 4.0

PCI Express Configurations ‡

Up to 1x16+4, 2x8+4

Max # of PCI Express Lanes

Package Specifications

Sockets Supported

FCLGA1700

Max CPU Configuration

Thermal Solution Specification

PCG 2020A

TJUNCTION

100°C

Package Size

45.0 mm x 37.5 mm

Max Operating Temperature

100 °C

Advanced Technologies

Intel® Volume Management Device (VMD)

Yes

Intel® Gaussian & Neural Accelerator

3.0

Intel® Thread Director

Yes

Intel® Deep Learning Boost (Intel® DL Boost) on CPU

Yes

Intel® Speed Shift Technology

Yes

Intel® Adaptive Boost Technology

Yes

Intel® Thermal Velocity Boost

Yes

Intel® Turbo Boost Max Technology 3.0 ‡

Yes

Intel® Turbo Boost Technology ‡

2.0

Intel® Hyper-Threading Technology ‡

Yes

Intel® 64 ‡

Yes

Instruction Set

64-bit

Instruction Set Extensions

Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2

Idle States

Yes

Enhanced Intel SpeedStep® Technology

Yes

Thermal Monitoring Technologies

Yes

Security & Reliability

Intel® Standard Manageability (ISM) ‡

Yes

Intel® Control-Flow Enforcement Technology

Yes

Intel® AES New Instructions

Yes

Secure Key

Yes

Intel® OS Guard

Yes

Execute Disable Bit ‡

Yes

Intel® Boot Guard

Yes

Mode-based Execute Control (MBEC)

Yes

Intel® Virtualization Technology (VT-x) ‡

Yes

Intel® Virtualization Technology for Directed I/O (VT-d) ‡

Yes

Intel® VT-x with Extended Page Tables (EPT) ‡

Yes
